Drawing Size(inch)（Round） Product number LCD type Resolution Driver IC Interface Pin number Outline size(mm) AA size(mm) Touch Function
0.9 TFT009B001 IPS 240x240 ST7735P3 SPI 25 25.24(H)*27.14(V)*1.55(T) 23.04(H)*23.03(V)
0.9 TFT009B003 IPS 128x128 ST7735 SPI 10 25.24(H)*27.14(V)*1.55(T) 23.04(H)*23.03(V)
TFT012B002.pdf 1.2 TFT012B002 IPS 240x240 NV3002B QSPI 24 32.54(H)*34.56(V)*1.65(T) 30.24(H)*30.24(V)
1.28 TFT128H005 IPS 240x240 GC9A01 SPI 30 35.6(H)*37.74(V)*1.56(T) 32.4(H)*32.4(V)
1.28 TFT128HT005 IPS 240x240 GC9A01 SPI 30 46(H)*46(V)*3.09(T) 32.4(H)*32.4(V) CTP
TFT132B013.pdf 1.32 TFT132B013 IPS 360x360 ST77916 QSPI 16 35.98(H)*38.54(V)*1.6(T) 33.48(H)*33.48(V)
1.38 TFT138B005 IPS 240x240 NV3002A SPI 24 37.54(H)*39.12(V)*1.65(T) 35.14(H)*35.14(V)
TFT138B005.pdf 1.38 TFT138BT005 IPS 240x240 NV3002A SPI 24 39.12(H)*41.4(V)*3.34(T) 35.14(H)*35.14(V) CTP
TFT146B005.pdf 1.46 TFT146B005 IPS 360x360 ST77916 QSPI 24 39.3(H)*40.96(V)*1.6(T) 36.94(H)*36.94(V)
1.6 TFT016B012 IPS 400x400 ST77903 SPI 23 42.14(H)*44.24(V)*1.96(T) 39.84(H)*39.84(V)
1.6 TFT016BT012 IPS 400x400 ST77903 QSPI 23 53(H)*53(V)*3.49(T) 39.84(H)*39.84(V) CTP
TFT021T005-C0.pdf 2.1 TFT021T005-C0 IPS 480x480 ST7701S MCU 40 56.18(H)*59.71(V)*2.26(T) 53.28(H)*53.28(V)
2.76 TFT276B009 IPS 480x480 ST7701S MIPI 30 73.03(H)*76.48(V)*2.45(T) 70.13(H)*70.13(V)
2.76 TFT276BT010 IPS 480x480 ST7701S MIPI 30 81.8(H)*81.26(V)*1.2(T) 70.13(H)*70.13(V) CTP,GFF
3.4 TFT034B003 IPS 800x800 JD9365DA MIPI 40 94.9(H)*96.95(V)*2.26(T) 87.6(H)*87.6(V)
TFT036B003.pdf 3.6 TFT036B003 IPS 544x506 ST72566 RGB 40 98.88(H)*94.12(V)*7.7(T) 89.76(H)*83.49(V)
TFT036B004.pdf 3.6 TFT036B004 IPS 544x506 ST72566 RGB 40 98.88(H)*94.12(V)*7.7(T) 89.76(H)*83.49(V)
TFT040B015.pdf 4 TFT040B015 IPS 720x720 ICNL9707 MIPI 37 110(H)*113.49(V)*7.8(T) 101.52(H)*101.52(V)
